• White-coated sheet
• High transmission extruded PC or PMMA frosted lens, UGR<22
• 80 & 90 CRI Options
• Standard and High Performance lumen packages up to 125 lumens per watt
• CCT and Wattage adjustable
|
|
PRODUCT CODE | FINISH | WATTAGE | CCT | IP | BEAM ANGLE | LM | LM/W | DLC 5.1 |
|
|---|---|---|---|---|---|---|---|---|---|---|
|
SNT-TRS1LED20-2×2 | White | 20/15/10 | 3500/4000/5000K | IP20 | - |
2500/2520/2540 |
125/126/127 | Premium | Datasheet |
|
|
SNT-TRS1LED25-2×2 |
White | 25/20/15 | 3500/4000/5000K | IP20 | - |
3125/3150/3375 |
125/126/127 | Premium | Datasheet |
|
|
SNT-TRS1LED30-2×2 |
White | 30/25/20 | 3500/4000/5000K | IP20 | - |
3750/3780/3810 |
125/126/127 | Premium | Datasheet |
|
|
SNT-TRS1LED34-2×4 |
White |
34/30/25 |
3500/4000/5000K |
IP20 |
- |
4250/4284/4318 |
125/126/127 |
Premium |
Datasheet |
|
|
SNT-TRS1LED38-2×4 |
White |
38/34/30 |
3500/4000/5000K |
IP20 |
- |
4750/4788/4826 |
125/126/127 |
Premium |
Datasheet |
|
|
SNT-TRS1LED45-2×4 |
White |
45/38/34 |
3500/4000/5000K |
IP20 |
- |
4625/5670/5715 |
125/126/127 |
Premium |
Datasheet |
|
|
SNT-TRS1LED20-1×4 |
White |
20/15/10 |
3500/4000/5000K |
IP20 |
- |
2500/2520/2540 |
125/126/127 |
Premium |
Datasheet |
|
|
SNT-TRS1LED25-1×4 |
White |
25/20/15 |
3500/4000/5000K |
IP20 |
- |
3125/3150/3375 |
125/126/127 |
Premium |
Datasheet |
|
|
SNT-TRS1LED30-1×4 |
White |
3025/20 |
3500/4000/5000K |
IP20 |
- |
3750/3780/3810 |
125/126/127 |
Premium |
Datasheet |
|
|
PRODUCT CODE | FUNCTION NAME | DESCRIPTION |
|
|---|---|---|---|---|
 |
ANT-15P | Sensor |
Passive infrared occupancy dual-level sensor that is installed as a fixed sensor on indoor luminaries and provides daylight capture control. All control parameters (hold time, task light level, standby level, standby time) can be adjusted by dip switch, and task light level can also be controlled by remote control. |
Datasheet |
 |
MS007 | Sensor | Moving object sensor with a detection range of 360° and an operating frequency of 5.8GHz. The advantage of this product is that the working state is stable (stable working temperature :-40°C-+70°C), ANT-7 uses microwave sensor (high-frequency output <0.2mW), and the safety performance is better than the infrared sensor. | Datasheet |
 |
YH28-X | Emergency Pack |
Suit for 8W to 200W lamp with external led driver, |
Datasheet |
