• PC diffuser, PC base, Metal gear tray
• LED module prefixed with diffuser
• Ultra-wide surface mount distance
• Surface conduit mounting guides
• Cross-shaped end cap
• Tool less for through wiring
• Side clips can be locked at 70 degrees
• Detachable Terminal Block with Multiple Positions
• Function Options: Microwave Sensor, Emergency Pack, PWM Sensor, DAIL
|
|
PRODUCT CODE | FINISH | WATTAGE | CCT | IP | BEAM ANGLE | LM | LM/W |
|
|---|---|---|---|---|---|---|---|---|---|
|
SVLED106-CCT1 |
Grey |
10W |
4000K |
IP66 |
120° |
1280max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED206-CCT1 |
Grey |
20W |
4000K |
IP66 |
120° |
2560max |
140/160/180/200 |
Datasheet |
|
|
SVLED206-CCT3 |
Grey |
18/15/11/9W |
3000/4000/6500K |
IP66 |
120° |
2560max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED112-CCT1 |
Grey |
20W |
4000K |
IP66 |
120° |
2560max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED212-CCT1 |
Grey |
40W |
4000K |
IP66 |
120° |
5120max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED112-CCT3 |
Grey |
18/15/11/9W |
3000/4000/6500K |
IP66 |
120° |
2560max |
140/160/180/200 |
Datasheet |
|
|
SVLED212-CCT3 |
Grey |
36/30/24/18W |
3000/4000/6500K |
IP66 |
120° |
5120max |
140/160/180/200 |
Datasheet |
|
|
SVLED115-CCT1 |
Grey |
30W |
4000K |
IP66 |
120° |
3600max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED215-CCT1 |
Grey |
60W |
4000K |
IP66 |
120° |
7200max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED215-CCT1 |
Grey |
58W |
4000K |
IP66 |
120° |
8120max |
140/160/180/200 |
Datasheet |
|
|
SVLED115-CCT3 |
Grey |
23/19/15/12W |
3000/4000/6500K |
IP66 |
120° |
3240max |
140/160/180/200 |
Datasheet |
|
|
SVLED215-CCT3 |
Grey |
46/38/30/24W |
3000/4000/6500K |
IP66 |
120° |
6480max |
140/160/180/200 |
Datasheet |
|
|
SVLED215-CCT3 |
Grey |
58/49/40/31W |
3000/4000/6500K |
IP66 |
120° |
8120max |
140/160/180/200 |
Datasheet |
|
|
SVLED118-CCT1 |
Grey |
40W |
4000K |
IP66 |
120° |
4860max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED218-CCT1 |
Grey |
80W |
4000K |
IP66 |
120° |
9600max |
120/140/160/180/200 |
Datasheet |
|
|
SVLED118-CCT3 |
Grey |
34/29/24/19W |
3000/4000/6500K |
IP66 |
120° |
4860max |
140/160/180/200 |
Datasheet |
|
|
SVLED218-CCT3 |
Grey |
68/58/48/38W |
3000/4000/6500K |
IP66 |
120° |
9720max |
140/160/180/200 |
Datasheet |
|
|
PRODUCT CODE | FUNCTION NAME | DESCRIPTION |
|
|---|---|---|---|---|
 |
BVP--Athena | Sensor |
DC Input,DIP switch Detection distance 6-12m On-off sensing and 3 levels of dimming control optional |
Datasheet |
 |
BVP--Medusa | Emergency kit |
Integral Emergency Kit 3 hours emergency working time Easy to replace lithium iron phosphate battery pack Manual quick function test button |
Datasheet |
